TRICONEX 3625A 32-Point TMR Digital Output Module

Name: TRICONEX 3625A 32Point TMR Digital Output Module
Brand: Triconex
Price: 1 USD

Quality TRICONEX 3625A 32-Point TMR Digital Output Module for sale

Packaging Details : Brand new and original

Freight Collect : Customer DHL/FedEx Account Supported

Place of Origin : USA

Supply Ability : in stock

Delivery Time : 2-3 work days

MOQ : 1 Piece

MOQ : 1

Shipping Carriers : DHL | FedEx | UPS | TNT | Aramex (Global Shipping Available)

Brand Name : Triconex

Quotation Time : Quick Quote Within 24 Hours

Payment Terms : T/T

Contact Now

Key Specifications

Core identification data for the module.

32 digital output points

TMR triple-modular-redundant architecture

24 VDC nominal field output voltage

Commoned field output arrangement

Supervised point supervision available

Tricon v10.2+ specified system generation

Technical Specifications

Specification	3625A
Module type	32-point TMR supervised / non-supervised digital output module
Output signals	32, commoned
Nominal voltage	24 VDC
Recommended voltage range	16–32 VDC
Maximum voltage	36 VDC
Logic power	< 13 W
Maximum current rating	1.70 ± 10% A per point; 5 A surge for 7 ms
Total module output current	10 A per termination panel
Minimum required load	10 mA
Maximum output leakage	2.0 mA at 24 VDC; 2.5 mA at 32 VDC
Field termination fuses	Not required; output switches are self-protected against over-voltage, over-temperature and over-current
System-to-field isolation	1,500 VDC minimum

View additional technical specifications

Point supervision	Can be programmed per point
Short/open detection	Programmable per supervised point
Module status indicators	PASS, FAULT, LOAD, ACTIVE
Point indicators	One On/Off status indicator per point
Field alarm	LOAD, one per point
Maximum output diagnostic toggle rate	Every 60 ms
Diagnostic glitch duration	2 ms maximum; 200 μs typical
On-state voltage drop at backplane	< 0.16 VDC typical at 250 mA; < 1.12 VDC typical at 1.7 A
On-state voltage drop with 10-foot cable	< 1.15 VDC typical at 250 mA; < 3.33 VDC typical at 1.7 A
On-state voltage drop with 99-foot cable	< 2.71 VDC typical at 250 mA; < 8.92 VDC typical at 1.7 A
Inductive kick-back protection	Output switches are self-protected
Color code	Dark blue
Specified system generation	Tricon v10.2 and later

Manufacturer documentation: Invensys, Planning and Installation Guide for Tricon v9–v11 Systems, Document No. 9720077-019.

Compatibility & Replacement

Original compatibility

Specified for Tricon v10.2 and later systems. The 3625A uses 16-point commoned field termination panels.

Historical replacement

The 3625A is a modified version of the 3625 and is documented as fully compatible with 3625 applications.

Application & Fault Scenarios

System role

Used inside a Tricon safety control system to provide discrete field outputs through a TMR output architecture.

LOAD fault

Check field power, load condition and termination wiring.

FAULT indication

Review module diagnostics and associated field conditions.

Output unavailable

Check configuration, wiring and field supply before replacing the module.

Maintenance impact: an unavailable output module can affect the associated discrete output function and extend troubleshooting or planned maintenance time.

Installation & Field Connection

Chassis & slot

Confirm the configured chassis and logical slot before installation. Tricon I/O modules are mechanically keyed for their configured positions.

Termination panel

Digital output modules require a separate field termination assembly and cable interface to the controller backplane.

Field power

The 3625A separates field power into two 16-point groups with a common return.

Supply arrangement

Verify the field supply arrangement against the applicable installation documentation before commissioning.

Redundancy & Diagnostics

TMR architecture

Three redundant channels participate in the output architecture.

Output voting

Redundant output paths use voting to control the field output.

Loopback diagnostics

Voltage and current loopback circuitry supports output fault detection.

Point supervision

Supervision and short/open detection can be programmed per supervised point.

Before replacement, compare the installed system generation, termination arrangement, output configuration and field power setup with the applicable 3625A manual.
