PM590-ETH 1SAP150000R0271 ABB Processor Module – 2 MB Ethernet AC500

Product Categories
AMIKON LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

PM590-ETH 1SAP150000R0271 ABB Processor Module – 2 MB Ethernet AC500

  • 1
  • 2
  • 3

Place of Origin : SWEDEN

Delivery Time : 2-3 work days

Brand Name : ABB

MOQ : 1

Payment Terms : T/T

Contact Now

Description

Processor module for the ABB AC500 system with integrated Ethernet, two configurable serial interfaces, one FieldBusPlug interface and an LCD display.

Part Number
1SAP150000R0271

Technical Parameters

Memory & processing
Program memory 2048 kB
Integrated user data memory 3072 kB
Saved data memory 536 kB
Minimum instruction time Bit: 0.002 µs · Word: 0.004 µs · Floating point: 0.004 µs
Memory card Plug-in memory card supported
Communication interfaces
Ethernet 1 integrated Ethernet interface
Ethernet functions TCP/IP, UDP/IP, Modbus TCP, web server, IEC 60870-5-104, SNTP, DHCP, FTP server, HTTP, SMTP and PING
COM1 RS-232 / RS-485 configurable; programming, Modbus RTU, ASCII and CS31 master
COM2 RS-232 / RS-485 configurable; programming, Modbus RTU and ASCII
FieldBusPlug 1 interface
Electrical & physical data
Supply voltage 24 V DC
Supply range 20.4 … 28.8 V DC
Current consumption 0.150 A typical, module alone
Display LCD display with 8 function keys
Mounting TH35-15 mounting rail according to IEC 60715
Protection rating IP20
Dimensions 67.5 mm W × 76 mm H × 62 mm D
Product net weight 0.137 kg
Source: ABB AC500 technical data, AC500 Hardware Manual 3ADR010121 and ABB product record 1SAP150000R0271.

Installation & Configuration

Mounting

Install the module on the specified TH35-15 mounting rail within the AC500 assembly.

Terminal base

Use the corresponding AC500 terminal-base arrangement for the installed controller configuration.

Engineering

Use Automation Builder for AC500 hardware configuration, programming and commissioning.

Documentation

Check the PM590-ETH datasheet when matching the module to an existing project or spare-parts requirement.

Application & Fault Search

AC500 Control

Controller replacement

Suitable for AC500 controller applications requiring the PM590-ETH processor configuration.

Network

Ethernet communication

For communication or remote-access problems, first check power, network connection and controller status.

Serial

RS-232 / RS-485 fault search

Check the selected interface mode, communication settings, cabling and connected device.

CPU

Unexpected controller stop

Check the processor status and project condition before removing or replacing the module.

Request a Quote

AMIKON Industrial Automation
PM590-ETH Spare Parts Support
Contact: Miya Zheng
Email
sales@amikon.cn
WhatsApp
+86 180 2077 6792
RFQ Details
Part Number Quantity Destination Required Date Machine/System Model
Product inspection and export packaging are arranged according to the order condition, with AMIKON one-year warranty and after-sales support.
PM590-ETH 1SAP150000R0271 ABB Processor Module – 2 MB Ethernet AC500
WAREHOUSE · INSPECTION
PM590-ETH 1SAP150000R0271 ABB Processor Module – 2 MB Ethernet AC500
SERVICE · SUPPORT
Global Supply Network
Industrial automation parts across 120+ countries
AMIKON supports customers across Asia, Europe, North America, South America and the Middle East, connecting international customers with industrial automation spare parts and technical service.
Asia
China · Japan · Southeast Asia
Europe
EU · UK · Eastern Europe
Americas
North America · South America
Middle East
Regional industrial supply

Delivery & Warranty

Testing Inspection and applicable functional testing before dispatch.
Packaging Protective export packaging for industrial shipments.
Warranty One-year AMIKON warranty within the applicable scope.
DOA / Returns Handled through the AMIKON after-sales process.

FAQ

What is the ABB PM590-ETH order code?
The order code is 1SAP150000R0271.
How much program memory does PM590-ETH have?
PM590-ETH has 2048 kB program memory.
Does ABB PM590-ETH have Ethernet?
Yes. It has one integrated Ethernet interface with functions including TCP/IP, Modbus TCP, web server and IEC 60870-5-104.
What serial interfaces are available on PM590-ETH?
It provides two configurable RS-232 / RS-485 interfaces. COM1 also supports CS31 master operation.
What should I check before ordering a PM590-ETH replacement?
Check the installed order code, AC500 terminal-base configuration and system setup before replacement.
