Bently Nevada 200155-00-CN Low Frequency Trendmaster Pro Accelerometer
The 200155-00-CN is a low-frequency accelerometer for Trendmaster Pro vibration monitoring where stable measurement of low-speed machinery response is required.
Performance & Order-Code Details
The values below are limited to the official 200150/200155/200157 accelerometer datasheet and the ordering option identified by this exact model.
View 7 specifications — sensor performance⌄
View 5 specifications — electrical interface⌄
View 6 specifications — mechanical and environmental⌄
Low-Frequency Channel & Mounting Choice
Use the -05 input
The long-settling 200155 family is specified for a low-frequency acceleration-to-velocity channel.
Plan the mounting hardware
Option 00 supplies no mounting stud; the sensor interface is 3/8-24 UNF-2B female.
Allow the bias to settle
The official settling-time limit is 2,000 ms to within 5% of bias.
Where 200155-00-CN Fits
Signal Checks
Unstable vibration value
Check sensor seating, mounting hardware, connector condition and cable continuity.
Bias does not settle
Confirm the -05 low-frequency input, 4.7–5.5 Vdc excitation and the allowed settling time.
No vibration signal
Trace the complete sensor–cable–channel loop and confirm the correct input type.
How Amikon Handles This Order
Four clear steps from part-number review to post-delivery support.
Order Review
Part number, quantity, destination, required date and system context checked first.
Inspection & Testing
Identity, condition and applicable functional checks recorded before dispatch.
Packing & Dispatch
Protected industrial packing with shipment tracking.
DOA, Returns & Support
DOA, returns, warranty and after-sales follow the quoted order terms.
Multi-brand Spare Parts Also Requested
These models are independent procurement references only. They are not substitutes for 200155-00-CN. Compatibility, configuration and stock must be confirmed separately for every request.
RFQ Information
For a faster order review, please provide:
Before Ordering 200155-00-CN
When should a buyer choose 200155-00-CN instead of a 200150 sensor?⌄
200155-00-CN is the 200155 low-frequency version: its 2 Hz lower frequency limit and dedicated low-frequency A-V channel suit slower vibration measurement. Bently Nevada does not identify it as interchangeable with 200150.
Will 200155-00-CN work on a standard acceleration-to-velocity channel?⌄
Do not assume so. Because the 200155 can take up to 2,000 ms to settle, Bently Nevada specifies the low-frequency A-V channel option -05.
What mounting hardware arrives with 200155-00-CN?⌄
Option 00 means no mounting stud is supplied. Match the sensor's 3/8-24 UNF-2B female interface to the approved site mounting arrangement.
Why can 200155-00-CN remain near bias just after connection?⌄
The sensor may require up to 2,000 ms to settle. Confirm 4.7 to 5.5 Vdc excitation and a +2.5 ±0.23 Vdc bias before treating the sensor as failed.
How should cable problems be ruled out for 200155-00-CN?⌄
Keep the cable within the official 15.24 m (50 ft) limit, then check the 5-pin connector, continuity and the complete sensor-to-channel loop.
What must match before an outage replacement with 200155-00-CN?⌄
Match the full -00-CN code, low-frequency -05 channel, mounting hardware, cable length and installed machine details.
